ABB ACS880 Series Quick Start Up Guide

71
TIA portal
Contents of this chapter
This chapter provides the examples for configuring S7-300 and S7-1200 series PLC. You can configure
S7-300, S7-400, S7-1200 and S7-1500 series PLC using TIA portal.
Configuring PC IP address
To configure PC IP address, follow these steps:
Navigate to Control Panel → Network and Sharing Center → Local Area Connection in the PC.
1. In the Local Area Connection Status window, click Properties.
Figure 48 LAC
4

ABB ACS880 Series Specifications

General

Cooling Method	Air-cooled, liquid-cooled
Enclosure class	IP21, IP55
Mounting type	Wall-mounted
Control method	Direct torque control (DTC)
Braking chopper	Integrated or external
Communication	Ethernet
Protection Features	Overcurrent, overvoltage, undervoltage, overload, short circuit, overtemperature, earth fault
Operating Temperature Range	-15°C to +50°C
Storage Temperature Range	-40°C to +70°C
Relative Humidity	5 ... 95 % (non-condensing)
Safety features	Safe torque off (STO)
