ABB IRB 260 User Manual

6 Reference information
6.4. Screw joints
3HAC 026048-001 Revision: -188
© Copyright 2006 ABB. All rights reserved.
The table below specifies the recommended standard tightening torque for water and air
connectors when one or both connectors are made of brass.
Dimension
Tightening torque
Nm - Nominal
Tightening torque
Nm - Min.
Tightening torque
Nm - Max.
1/8 12 8 15
1/4 15 10 20
3/8 20 15 25
1/2 40 30 50
3/4 70 55 90
Continued
