7 Spare part lists and exploded views
7.5. Spare parts - axes 1-3
3HAC 026048-001 Revision: -208
© Copyright 2006 ABB. All rights reserved.
7.5. Spare parts - axes 1-3
Axes 1-3, spare part list
The items specified below are shown in the figures Axes 1-3, spare part view 1 on page 210
and Axes 1-3, spare part view 2 on page 211.
Item Qty Description Spare part no. Dimension
1 1 Base Foundry 3HAC025710-001 Recommended spare part.
2 1 Gearbox, axes 1-3 3HAC025711-001 Recommended spare part.
Replacement is detailed in
section Replacement of
gearbox, axis 1-3 on page
169.
3 12 Hex socket head cap screw - M12x50 Steel 8.8 Gleitmo
610
4 12 Plain washer 9ADA312-9 13x24x2.5
5 2 Motor unit, axes 1 and 3 3HAC025712-001 Recommended spare part.
Replacement is detailed in
section Replacement of
motor, axis 1 on page 151
and Replacement of
motor, axis 3 on page 161.
6 3 O-ring 21522012-434 Recommended spare part.
7 12 Spring washer 21542033-9 8.4x18x2
8 4 Hex socket head cap screw - M8x65 Steel 12.9 Gleitmo
610
9 8 Hex socket head cap screw 3HAB3409-37 M8x25
11 8 Spring washer 21542033-10 10.5x23x2.5
12 12 Hex socket head cap screw 3HAB3409-50 M10x40
13 1 Spring tension plate 3HAC2205-1
14 1 Damper standard, axis 2 3HAC2180-1
15 1 Damper, axis 3 3HAB5512-1
16 4 Torx pan head roll. screw 9ADA629-56 M6x16
17 8 Hex socket head cap screw 3HAB3409-57 M10x60
19 2 Sealing ring (V-ring) 3HAB3732-13 Recommended spare part.
32 1 Bearing sealing 3HAC10088-4 Recommended spare part.
33 1 Locking washer 3HAB5523-1 D=34; T=4
34 1 Hex socket counters, head 21212852-449 M8x16
35 1 Bearing sealing 3HAC10089-2 Recommended spare part.
36 1 Motor unit, axis 2 3HAC025713-001 Recommended spare part.
Replacement is detailed in
section Replacement of
motor, axis 2 on page 156.
41 14,700
ml
Lubricating oil 11712016-604
42 165g Bearing grease 3HAB3537-1 Shell Alvania WR2
43 1 ml Locking liquid - Loctite 243
46 1 Stop, axis 1 3HAB6687-1
Continues on next page
