Cross section, guide sleeve hole
The figure below shows the cross section of the guide sleeve holes (from previous figure):
xx0200000182
Guide sleeves
Two guide sleeves can be fitted to the two rear bolt holes to allow the same robot to be
remounted without re-adjusting the program.
Equipment Art. no.
Guide sleeves 2151 0024-169
Continued
