4.4.6 Replacing the linkage - link
Overview
The linkage consist of three basic parts - upper link arm, lower link arm and link.
This procedure describes how to remove and refit the link.
How to replace the upper and lower link arms see:
• Replacing linkage - upper link arm on page 225
• Replacing linkage - lower link arm on page 233
Location of link
The link is located as shown in the figure.
xx1100000167
A Upper link arm
B Link
C Lower link arm
Continues on next page
240 Product manual - IRB 460
3HAC039842-001 Revision: P
© Copyright 2012-2018 ABB. All rights reserved.
4 Repair
4.4.6 Replacing the linkage - link
