7.7 Special tools
General
All service instructions contain lists of tools required to perform the specified
activity. The required tools are a sum of standard tools, defined in the section
Standard tools on page 383, and of special tools, listed directly in the instructions
and also gathered in this section.
Calibration equipment, Calibration Pendulum
The following table specifies the calibration equipment needed when calibrating
the robot with the Calibration Pendulum method.
The robot is calibrated by either Calibration Pendulum or Axis Calibration at factory.
Always use the same calibration method as used at the factory.
Information about valid calibration method is found on the calibration label or in
the calibration menu on the FlexPendant.
If no data is found related to standard calibration, Calibration Pendulum is used
as default.
NoteArt. no.Description
Complete kit that also includes operating
manual.
3HAC15716-1Calibration Pendulum toolkit
Calibration equipment, Axis Calibration
The following table specifies the calibration equipment needed when calibrating
the robot with the Axis Calibration method.
The robot is calibrated by either Calibration Pendulum or Axis Calibration at factory.
Always use the same calibration method as used at the factory.
Information about valid calibration method is found on the calibration label or in
the calibration menu on the FlexPendant.
If no data is found related to standard calibration, Calibration Pendulum is used
as default.
NoteArt. no.Description
Delivered as a set of calibration tools.3HAC062326-
001
Calibration tool box, Axis Cal-
ibration
Required if Axis Calibration is the valid
calibration method for the robot.
Special tools
This table specifies the special tools required during several of the service
procedures. The tools are specied directly in concerned instructions.
Article no.QtyDescription
3HAC022637-0012Guide pins M12x130
3HAC13120-22Guide pins M10x150
Continues on next page
