2.7 Electrical connections
2.7.1 Robot cabling and connection points
Introduction
Connect the robot and controller to each other after securing them to the foundation.
The lists below specify which cables to use for each respective application.
Main cable categories
All cables between the robot and controller are divided into the following categories:
DescriptionCable category
Handles power supply to and control of the robot's motors
as well as feedback from the serial measurement board.
Robot cables
Specified in the table Robot cables on page 94.
Handles communication with equipment fitted on the robot
by the customer, low voltage signals and high voltage power
supply + protective ground.
Customer cables (option)
See the product manual for the controller, see document
number in References on page 10.
Robot cables
These cables are included in the standard delivery. They are completely
pre-manufactured and ready to plug in.
Connection
point, robot
Connection
point, cabinet
DescriptionCable sub-category
R1.MPXS1Transfers drive power from the
drive units in the control cabinet
to the robot motors.
Robot cable, power
R1.SMBXS2Transfers resolver data from
and power supply to the serial
measurement board.
Robot cable, signals
Robot cable, power
Art. no.Cable
3HAC026787-001Robot cable, power: 7 m
3HAC026787-002Robot cable, power: 15 m
3HAC026787-003Robot cable, power: 22 m
3HAC026787-004Robot cable, power: 30 m
Robot cable, signals
Art. no.Cable
3HAC2493-1Robot cable signal, shielded: 7 m
3HAC2530-1Robot cable signal, shielded: 15 m
3HAC2540-1Robot cable signal, shielded: 22 m
3HAC2566-1Robot cable signal, shielded: 30 m
Continues on next page
94 Product manual - IRB 460
3HAC039842-001 Revision: P
© Copyright 2012-2018 ABB. All rights reserved.
2 Installation and commissioning
2.7.1 Robot cabling and connection points
