153
Chapter 7 Replaceable Parts
33250-66511 – Main PC Assembly (A1)
4
7
33250-66511 – Main PC Assembly (A1)
Reference
Designator
Agilent Part
Number
Qty Part Description
Mfr.
Code
Mfr. Part Number
C101 - C102 0160-7798 288 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C103 0160-5947 11 CAP-FXD 1000pF 50 V 02010 08055C102KAT A
C104 - C107 0160-7736 56 CAP-FXD 1uF +-10% 16 V CER X7S 06352 C3216X7R1C105K
C108 0160-5961 2 FIXED CAPACITOR; 22PF 50 VOLTS 02010 08055A220JAT A
C109 0160-5957 4 CAP-FXD 47pF +-5% 50 V CER C0G 02010 08055A470JAT A
C110 - C113 0160-7736 CAP-FXD 1uF +-10% 16 V CER X7S 06352 C3216X7R1C105K
C114 0180-4918 1 CAP 100UF 10V 20% TANTD 05524 293D107X0010D2
C115 - C125 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C201 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C202 0160-5947 CAP-FXD 1000pF 50 V 02010 08055C102KAT A
C203 - C205 0160-7736 CAP-FXD 1uF +-10% 16 V CER X7S 06352 C3216X7R1C105K
C206 - C229 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C301 - C323 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C401 0160-5947 CAP-FXD 1000pF 50 V 02010 08055C102KAT A
C402 0160-7061 3 CAP-FXD 2200pF 50 V 02010 08055C222KAT
C403 0180-3751 1 CAP-FXD 1uF +-20% 35 V TA 02010 TAJB105M035
C404 0160-7736 CAP-FXD 1uF +-10% 16 V CER X7S 06352 C3216X7R1C105K
C405 0180-4577 3 CAP-FXD 10uF +-20% 10 V TA 12340 T491B106M010AS
C406 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C407 0160-8361 4 CAP 0.22UF 25 V 06352 C2012X7R1E224K
C408 0160-5947 CAP-FXD 1000pF 50 V 02010 08055C102KAT A
C409 - C413 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C501 0160-7736 CAP-FXD 1uF +-10% 16 V CER X7S 06352 C3216X7R1C105K
C502 0160-5947 CAP-FXD 1000pF 50 V 02010 08055C102KAT A
C503 - C518 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C601 - C603 0160-7736 CAP-FXD 1uF +-10% 16 V CER X7S 06352 C3216X7R1C105K
C604 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C605 - C606 0160-7736 CAP-FXD 1uF +-10% 16 V CER X7S 06352 C3216X7R1C105K
C607 0180-4538 16 CAP-FXD 100uF +-20% 10 V TA 12340 T495X107M010AS
C608 0160-7736 CAP-FXD 1uF +-10% 16 V CER X7S 06352 C3216X7R1C105K
C609 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C610 0160-5945 21 C MLYS .01U 50V CAP. 02010 08055C103KAT A
C611 0160-5957 CAP-FXD 47pF +-5% 50 V CER C0G 02010 08055A470JAT A
C612 0160-7736 CAP-FXD 1uF +-10% 16 V CER X7S 06352 C3216X7R1C105K
C613 0160-5945 C MLYS .01U 50V CAP. 02010 08055C103KAT A
C614 0160-7736 CAP-FXD 1uF +-10% 16 V CER X7S 06352 C3216X7R1C105K
C615 0160-5945 C MLYS .01U 50V CAP. 02010 08055C103KAT A
C616 0160-5950 3 CAP-FXD 470pF 50 V 02010 08055A471JAT A
C617 - C618 0160-7736 CAP-FXD 1uF +-10% 16 V CER X7S 06352 C3216X7R1C105K
C619 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C620 0160-7911 2 CAP-FXD 4700pF +-1% 50 V CER C0G 12340 C1206C472F5GAC
C621 0160-7307 1 CAP-FXD 180pF 50 V 02010 08055A181FAT_A
