Agilent Technologies 33250A Service Guide

178
Chapter 7 Replaceable Parts
33250A Front-Panel Assembly
7
33250A Front-Panel Assembly
Reference
Designator
Agilent Part
Number
Qty Part Description
Mfr.
Code
Mfr. Part Number
ASY1 33250-60201 1 FRONT-PANEL ASSEMBLY
(includes 33250-40201 and 33250-40202)
02634 33250-60201
CBL2-CBL3 33250-61606 2 CABLE, 50 OHM, BNC - SMB 02634 33250-61606
CBL4 33250-61611 1 CABLE, 14 CONDUCTOR RIBBON 02364 33250-61611
CBL5 33250-61613 1 CABLE, 40 CONDUCTOR RIBBON 02634 33250-61613
KNB1 33250-87401 1 KNOB 02634 33250-87401
MP1 33250-40201 1 BEZEL, FRONT 02634 33250-40201
MP2 33250-40202 1 WINDOW FRAME 02634 33250-40202
NUT3 0535-0154 1 NUT-HEX SGL-CHAM M9.0 X 0.75 2MM-THK 11239 3-9-03
PAD1 33250-88001 1 KEYPAD 02634 33250-88001
PLT2 33250-04102 1 PLATE, PLASTIC BACKER PLATE 02634 33250-04102
PLT3 33250-44104 1 SUPPORT PLATE, FRONT PANEL 02634 33250-44104
SHD2 33250-00604 1 SHIELD- EMC 02634 33250-00604
WIN1 33250-49301 1 WINDOW, FRONT 02634 33250-49301
WSH3 2190-0016 1 WASHER-LK INTL T 3/8 IN .377-IN-ID 02440 2190-0016
