Chapter 7 Replaceable Parts
33250-66502 – Front-Panel PC Assembly (A2)
7
33250-66502 – Front-Panel PC Assembly (A2)
Reference
Designator
Agilent Part
Number
Qty Part Description
Mfr.
Code
Mfr. Part Number
C101 0160-7798 9 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C103 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C105 - C109 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C111 0180-4758 1 CAP-FXD 47uF +-20% 20 V TA 12340 T491D476M020AS
C117 - C118 0180-4538 2 CAP-FXD 100uF +-20% 10 V TA 12340 T495X107M010AS
C221 0160-5967 2 CF 100PF 5% 06352 C2012COG1H101J
C222 - C223 0160-7798 CAP 0.1UF 50V 10% X7R 0805 06352 C2012X7R1H104K
C224 0160-5967 CF 100PF 5% 06352 C2012COG1H101J
CR100 - CR107 1901-1227 8 DIODE-SWITCHING 75V 200MA 6NS TO-236 02910 BAS16
DS201 - DS215 1990-2411 15 GREEN LED 12416 CMD67-21VGC
E100 9164-0173 1 BEEPER, PC MOUNT 09939 PKM22EPP-4002 S
J100 1252-8157 1 CONN_FFC_VERT_FEM_40PIN_FP_SMT 03418 52559-4092
J101 1253-0078 1
CONN FFC VERT FEM 14PIN .5MM SMT FP SMC
02010
04-6214-014-010-800
L101 9170-1739 1
CORE-SHIELDING BEAD
11702 FBMH4532HM681
L102 9170-1663 1 CORE-SHIELDING BEAD 11702 FBMH4532HM132
L201 9170-1584 1 CORE MAGNETIC 06352 MMZ2012Y102B
P102 1253-3587 1 VERTICAL, SMT 4 POS 1.25MM PITCH 03418 53398-0490
Q100 1854-1037 1 TRANSISTOR NPN SI TO-236AA PD=350MW 00746 SST3904T116
R105 - R109 0699-3051 10 RESISTOR 10K +-1% .1W TKF TC=0+-100 00746 MCR10-F-1002
R120 - R121 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 00746 MCR10-F-1002
R123 - R124 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 00746 MCR10-F-1002
R200 - R214 0699-3059 15 RESISTOR 162 +-1% .1W TKF TC=0+-100 05524 CRCW08051620F
R216 0699-3051 RESISTOR 10K +-1% .1W TKF TC=0+-100 00746 MCR10-F-1002
S203 0960-0892 1 ROTARY ENCODER 11318 EC16B2410402A
U201 - U202 1821-0299 2 IC FF BICMOS/ABT D-TYPE POS-EDGE-TRIG 01698 74ABT273DW
U204 1826-2264 1 IC 34064 36633 MC34064D-5R2
