Performance Tests 7
146 Agilent U1602B/U1604B User’s and Service Guide
Resistance Verification Test
1 Put the calibrator in Standby (STBY) mode.
2 Select Meter mode of the instrument, then press F2 softkey for
Ohmmeter.
3 Press F1 to select resistance measurement.
4 Connect the calibrator to the instrument’s input and ground terminal as
shown in Figure 7- 2 using a banana plug.
5 Select each function and range in the order shown in Table 7- 7. Apply
the values from the calibrator shown in Table 7- 7 below.
6 Compare the measurement results to the corresponding test limits
shown in Table 7- 7.
Table 7 - 7 Resistance Verification Test
Calibrator Settings Function Range Min Limit Max Limit
600 Ω 2-Wire Ohms 600 Ω 595.8 Ω 604.2 Ω
6 kΩ 6 kΩ 5.958 kΩ 6.042 kΩ
60 kΩ 60 kΩ 59.58 kΩ 60.42 kΩ
600 kΩ 600 kΩ 595.8 kΩ 604.2 kΩ
3 MΩ 6 MΩ 2.973 MΩ 3.027 MΩ
6 MΩ 6 MΩ 5.958 MΩ 6.042 MΩ
60 MΩ 60 MΩ 59.28 MΩ 60.72 MΩ
