Performance Tests 7
148 Agilent U1602B/U1604B User’s and Service Guide
Diode Verification Test
1 Put the calibrator in Standby (STBY) mode.
2 Select Meter mode of the instrument, then press F2 softkey for
Ohmmeter.
3 Press F1 to select diode test.
4 Connect the calibrator to the instrument’s input and ground terminal as
shown in Figure 7- 2 using a banana plug.
5 Select each function and range in the order shown in Table 7- 9. Apply
the values from the calibrator shown in Table 7- 9 below.
6 Compare the measurement results to the corresponding test limits
shown in table 7- 9.
Table 7 - 9 Diode Verification Test
Calibrator Voltage Function Min Limit Max Limit
0.9 V Diode 0.8812 V 0.9188 V
