Capacitance Verification Test
1 Put the calibrator in Standby (STBY) mode.
2 Select Meter mode of the instrument, press F2 softkey for Ohmmeter.
3 Press F1 to select capacitance measurement.
4 Connect the calibrator to the instrument’s input and ground terminal as
shown in Figure 7- 2 using a banana plug.
5 Select each function and range in the order shown in Table 7- 8. Apply
the values from the calibrator shown in table 7- 8 below.
6 Compare the measurement results to the corresponding test limits
shown in table 7- 8.
Table 7 - 8 Capacitance Verification Test
Calibrator Settings Function Range Min Limit Max Limit
60 nF Capacitance 60 nF 58.68 nF 61.32 nF
600 nF 600 nF 586.8 nF 613.2 nF
6 mF6 mF5.868 mF6.132 mF
36 mF60 mF 35.16 mF 36.84 mF
60 mF60 mF 58.68 mF 61.32 mF
300 mF300 mF293.4 mF306.6 mF
