Allen-Bradley Kinetix 6000 Design Guide

Rockwell Automation Publication KNX-RM003B-EN-P - March 2019 103
Kinetix 6000 and Kinetix 6200/6500 Drive Systems
LDC-Series Performance Specifications with Kinetix 6000 (400V-class) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 50 °C (122 °F) ambient and rated line voltage. For additional
information on ambient and line conditions, see Motion Analyzer software.
Linear Motor
Speed, max
m/s (ft/s)
System Continuous
Stall Current
(1)
Amps 0-pk
(1) Values represent the range between no cooling (low value) and water cooling (high value).
System Continuous
Stall Force
(1)
N (lb)
System Peak
Stall Current
Amps 0-pk
System Peak
Stall Force
N (lb)
Linear Motor
Rated Output
kW
Kinetix 6000
400V-class Drives
LDC-C030100-DHT
10.0 (32.8)
4.1…6.1 74…111 (17…25) 12.1 188 (42) 0.37…0.55 2094-BM01-S @ 150%
LDC-C030200-DHT 8.1…12.2
148…222 (33…50)
24.3
375 (84) 0.74…1.11
2094-BM02-S @ 250%
LDC-C030200-EHT 4.1…6.1 12.1 2094-BM01-S @ 150%
LDC-C050100-DHT
10.0 (32.8)
3.9…5.9 119…179 (27…40) 11.7 302 (68) 0.59…0.89 2094-BM01-S @ 150%
LDC-C050200-DHT 7.9…11.8
240…359 (54…81)
23.3
600 (135) 1.20…1.79
2094-BM02-S @ 250%
LDC-C050200-EHT 3.9…5.9 11.6 2094-BM01-S @ 150%
LDC-C050300-DHT 11.8…17.7
363…544 (82…122)
35.9
941 (212) 1.81…2.72
2094-BM02-S @ 250%
LDC-C050300-EHT 3.9…5.9 12.0 2094-BM01-S @ 150%
LDC-C075200-DHT
10.0 (32.8)
7.7…11.5
348…523 (78…117)
22.9
882 (198) 1.74…2.61
2094-BM02-S @ 250%
LDC-C075200-EHT 3.8…5.7 11.5 2094-BM01-S @ 150%
LDC-C075300-DHT 11.5…17.2
523…784 (117…176)
35.6
1368 (308) 2.61…3.92
2094-BM02-S @ 250%
LDC-C075300-EHT 3.8…5.7 11.9 2094-BM01-S @ 150%
LDC-C075400-DHT 15.3…23.0
697…1045
(157…235)
47.4
1824 (410) 3.48…5.22
2094-BM03-S @ 250%
LDC-C075400-EHT 7.7…11.5 23.7
2094-BM02-S @ 250%
LDC-C100300-DHT
10.0 (32.8)
11.1…16.7
674…1012
(152…227)
34.3
1767 (397) 3.37…5.06
LDC-C100300-EHT 3.7…5.6 11.4 2094-BM01-S @ 150%
LDC-C100400-DHT 14.8…22.2
899…1349
(202…303)
45.7
2356 (530) 4.49…6.74
2094-BM03-S @ 250%
LDC-C100400-EHT 7.4…11.1 22.8 2094-BM02-S @ 250%
LDC-C100600-DHT 22.2…33.3
1349…2023
(303…455)
68.5
3534 (794) 6.74…10.11
2094-BM03-S @ 250%
LDC-C100600-EHT 11.1…16.7 34.3 2094-BM02-S @ 250%
LDC-C150400-DHT
10.0 (32.8)
14.1…21.1
1281…1922
(288…432)
45.2
3498 (786) 6.40…9.61
2094-BM03-S @ 150%
LDC-C150400-EHT 7.0…10.6 22.6 2094-BM02-S @ 250%
LDC-C150600-DHT 21.1…31.7
1922…2882
(432…648)
67.8
5246 (1179) 9.61…14.41
2094-BM03-S @ 250%
LDC-C150600-EHT 10.6…15.8 33.9 2094-BM02-S @ 250%
