Allen-Bradley Kinetix 6000 Design Guide

Rockwell Automation Publication KNX-RM003B-EN-P - March 2019 49
Kinetix 6000 and Kinetix 6200/6500 Drive Systems
Bulletin RDB Motor Performance Specifications with Kinetix 6200/6500 (400V-class) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 50 °C (122 °F) ambient and rated line voltage. For additional
information on ambient and line conditions, see Motion Analyzer software.
Motor Cat. No.
Base Speed
rpm
Speed, max
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW
Kinetix 6200/
Kinetix 6500
400V-class Drives
RDB-B21519 750 1235 9.9 31.2 (276) 27.3 83.1 (735) 3.64 2094-BM02-M
RDB-B2151C 1500 2125 17.3 31.3 (277) 46.4 82.8 (733) 5.23 2094-BM03-M
RDB-B21529 750 1035 12.2 43.4 (384) 32.8 111 (982) 4.33 2094-BM02-M
RDB-B2152C 1500 2125 23.5 43.4 (384) 63.2 111 (982) 6.41 2094-BM03-M
RDB-B21539 750 1250 15.8 51.5 (456) 47.9 137 (1212) 5.34 2094-BM03-M
RDB-B2153C 1500 2250 29.4 51.5 (456) 82.6 137 (1212) 5.87 2094-BM03-M
RDB-B29014 200 450 5.9 48.9 (433) 17.6 110 (973) 1.97 2094-BM01-M
RDB-B29016 375 785 10.0 48.9 (433) 31.0 110 (973) 3.18 2094-BM02-M
RDB-B29019 750 1500 19.1 48.9 (167) 58.7 110 (973) 3.63 2094-BM03-M
RDB-B29024 200 435 10.7 97.8 (865) 33.0 214 (1894) 3.33 2094-BM02-M
RDB-B29026 375 885 21.9 97.8 (865) 67.2 214 (1894) 4.05 2094-BM03-M
RDB-B29029 750 1200 36.2 97.5 (863) 97.8 195 (1726) 4.05 2094-BM05-M
RDB-B29034 200 500 17.4 140 (1239) 56.6 321 (2841) 5.16 2094-BM03-M
RDB-B29036 375 750 26.0 140 (1239) 84.9 318 (2814) 5.49 2094-BM05-M
RDB-B29039 750 1000 48.9 113 (1000) 97.8 194 (1717) 4.41 2094-BM05-M
RDB-B41014 200 385 17.8 183 (1619) 51.2 340 (3009) 5.20 2094-BM03-M
RDB-B41016 375 700 33.2 183 (1619) 95.5 339 (3000) 4.83 2094-BM05-M
RDB-B41018 625 700 48.9 175 (1549) 97.8 271 (2398) 4.83 2094-BM05-M
RDB-B41024 200 365 31.5 330 (2929) 95.5 690 (6107) 7.29 2094-BM05-M
