Rockwell Automation Publication KNX-RM003B-EN-P - March 2019 11
Kinetix 6000 and Kinetix 6200/6500 Drive Systems
Kinetix 6000 (200V-class) Drives with MP-Series Low Inertia Motors
This section provides system combination information for the Kinetix 6000 (200V-class) drives when matched with
MP-Series™ low-inertia motors. Included are motor power/brake and feedback cable catalog numbers, system
performance specifications, and the optimum torque/speed curves.
Bulletin MPL Motor Cable Combinations
For cable configuration illustrations and feature descriptions, by catalog number, see 2090-Series Motor/Actuator Cables Overview beginning on page 8.
Motor-end connector kits, and panel-mounted breakout components (drive end), are available for motor power/brake and feedback cables. See Optional Drive Accessories on page 6
.
Cable length xx is in meters. See the Kinetix Motion Accessories Technical Data, publication KNX-TD004
, for standard cable lengths.
IMPORTANT The MP-Series low-inertia motors on this page are equipped with DIN connectors (specified by 7 in the catalog number) and are
not compatible with cables designed for motors equipped with bayonet connectors (specified by 2 in the catalog number). The
motors with bayonet connectors (for example, MPL-A310P-xx2xAA) are being discontinued and require 2090-XXNxMP
(bayonet) cables. For help with migration or to select bayonet cables, contact your Rockwell Automation sales representative.
Motor Cat. No. (200V-class) Motor Power/Brake Cable Motor Feedback Cable
(1)
(1) Use low-profile connector kit (catalog number 2090-K6CK-D15M) with flying-lead cables on the drive end. See Required Drive Accessories on page 4.
MPL-A1510V-xx7xAA, MPL-A1520U-xx7xAA, MPL-A1530U-xx7xAA
2090-CPxM7DF-16AAxx (standard, non-flex)
2090-CPxM7DF-16AFxx (continuous-flex)
2090-CFBM7DF-CEAAxx or
(2)
(3)
2090-CFBM7DD-CEAAxx (standard, non-flex)
2090-CFBM7DF-CEAFxx or
2090-CFBM7DD-CEAFxx (continuous-flex)
Absolute High-resolution Feedback
2090-XXNFMF-Sxx (standard, non-flex)
(4)
2090-CFBM7DF-CDAFxx (continuous-flex)
Incremental Feedback
(2) Applies to Kinetix 6000 drives and MPL-A3xxx-M/S…MPL-A5xxx-M/S motors with absolute high-resolution feedback.
(3) Applies to Kinetix 6000 drives and MPL-A15xxx-V/E…MPL-A2xxx-V/E motors with absolute high-resolution feedback.
(4) Applies to Kinetix 6000 drives and MPL-A15xxx-H…MPL-A45xxx-H motors with incremental feedback.
MPL-A210V-xx7xAA, MPL-A220T-xx7xAA, MPL-A230P-xx7xAA
MPL-A310F-xx7xAA, MPL-A310P-xx7xAA,
MPL-A320H-xx7xAA, MPL-A320P,-xx7xAA, MPL-A330P-xx7xAA
MPL-A420P-xx7xAA, MPL-A430H-xx7xAA
MPL-A4530F-xx7xAA, MPL-A4540C-xx7xAA
MPL-A430P-xx7xAA
2090-CPxM7DF-14AAxx (standard, non-flex)
2090-CPxM7DF-14AFxx (continuous-flex)
MPL-A4530K-xx7xAA, MPL-A4540F-xx7xAA
MPL-A4560F-xx7xAA 2090-CPxM7DF-12AAxx (standard, non-flex)
MPL-A520K-xx7xAA
2090-CPxM7DF-10AAxx (standard, non-flex)
2090-CPxM7DF-10AFxx (continuous-flex)
MPL-A540K-xx7xAA, MPL-A560F-xx7xAA
2090-CPxM7DF-08AAxx (standard, non-flex)
2090-CPxM7DF-08AFxx (continuous-flex)
Bulletin MPL Motor Performance Specifications with Kinetix 6000 (200V-class) Drives
Rotary Motor
Cat. No.
Rated Speed
rpm
Speed, max
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW
Kinetix 6000
200V-class Drives
MPL-A1510V 8000 8000 1.05 0.26 (2.3) 3.40 0.77 (6.8) 0.16 2094-AMP5-S
MPL-A1520U 7000 7000 1.80 0.49 (4.3) 6.10 1.58 (13.9) 0.27 2094-AMP5-S
MPL-A1530U 7000 7000 2.82 0.90 (8.0) 10.1 2.82 (24.9) 0.39 2094-AMP5-S
MPL-A210V 8000 8000 3.09 0.55 (4.8) 10.2 1.52 (13.4) 0.37 2094-AMP5-S
MPL-A220T 6000 6000 4.54 1.61 (14.2)
10.5 3.45 (30.0)
0.62
2094-AMP5-S
15.5 4.74 (41.9) 2094-AM01-S
MPL-A230P 5000 5000 5.40 2.10 (18.6)
17.0 8.0 (70.8)
0.86
2094-AM01-S
23.0 8.2 (73.0) 2094-AM02-S
MPL-A310F 3000 3000 3.24 1.58 (14.0) 9.30 3.61 (31.9) 0.46 2094-AMP5-S
