Rockwell Automation Publication 2711R-UM001E-EN-E - January 2017 115
Appendix
A
Specifications
General Specifications
Attribute 2711R-T4T 2711R-T7T 2771R-T10T
Display type Color transmissive TFT active matrix LCD, widescreen format
Display size 4 in. 7 in. 10 in.
Display area 95 x 53.9 mm (3.74 x 2.12 in.) 153.6 x 86.6 mm (6.05 x 3.41 in.) 211.2 x 158.4 mm (8.31 x 6.24 in.)
Resolution (pixels) 480 x 272 800 x 480 800 x 600
Backlight lifespan, min 40,000 hours
Operator input Analog touch and function keys Analog touch
Memory card USB port and
micro-SD (Secure Digital) card – Industrial grade micro-SD cards recommended. Supports SDSC and Class
6 & Class 10 SDHC micro-SD cards, FAT32/16 formats, up to 32 GB maximum size.
Programming port Ethernet port
Battery lifespan, min 5 years @ 25 °C (77 °F)
Real-time clock Yes
Input voltage range 18…32V DC (24V DC nom)
Power consumption, max 9 W (0.39 A @ 24V DC) 11 W (0.40 A @ 24V DC) 14 W (0.48 A @ 24V DC)
Weight, approx. 0.333 kg (0.73 lb) 0.651 kg (1.44 lb) 1.64 kg (3.62 lb)
Dimensions (HxWxD), approx. 116 x 138 x 43 mm
(4.56 x 5.43 x 1.69 in.)
144 x 197 x 54 mm
(5.67 x 7.75 x 2.11 in.)
225 x 287 x 55 mm
(8.86 x 11.3 x 2.16 in.)
Wire size Input Power Terminal Block
Stranded or solid, Cu 90 °C (194 °F)
Single-Wire Gauge: 0.33…2.08 mm
2
(22...14 AWG)
Dual-wire Gauge: 0.33…1.31 mm
2
(22…16 AWG)
Wire type Copper
Wiring category
(1)
3 – on power ports
2 – on communication ports
Enclosure type ratings Meets NEMA/UL Type 4X (indoor) 12, 13, and IP65
North American Temp Code T4A
(1)
Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1.
