20 Rockwell Automation Publication 2711R-UM001E-EN-E - January 2017
Chapter 2 Configuration Mode
Configure Using the Terminal
The on-terminal interface lets you make changes to the terminal settings. The
menu is displayed on the left side of the terminal screen. Changes can be made
whether an application is running or not running.
Terminal Interface Main Menu
Terminal Settings
Terminal settings can be configured either through the PanelView Explorer
browser
(1)
interface or through the on-terminal interface.
Main
File Manager
Communication
Display
System Information
Current Application
Config Language Date and Time
Day Hour
Reset Terminal
Goto
14 10
Month Minute
1 30
Year Second
2015 56
English
Português
Français
Italiano
Deutsch
Español
简体中文
(1)
The PanelView Explorer feature is not supported on PanelView 800 terminals from firmware revision 3.011
onwards.
