Rockwell Automation Publication 2711R-UM001E-EN-E - January 2017 97
Recipes Chapter 7
c. select a numeric or string data type for the ingredient.
d. enter a minimum and maximum value for the ingredient if the data type
is numeric.
e. enter a value for each ingredient.
Delete Ingredients from a Recipe
Follow these steps to delete ingredients from a Recipe.
1. Click the space on the left of the ingredient to select the entire row.
2. Click Delete Ingredient.
3. Click Yes to confirm.
Download Recipes
Recipes are downloaded together with the application into the PanelView 800
terminal. See Downloading Applications
on page 59 for information on how to
download applications to the terminal.
