3-18 Programming and Parameters
Terminal Block Group (continued)
T065 [Opto Out Sel] Related Parameter(s): P033, T066, T068, T072
T076, A163, d318
Determines the operation of the programmable opto output.
Options 0 “Ready/Fault” Opto output is active when power is applied. This indicates
that the drive is ready for operation. Opto output is inactive
when power is removed or a fault occurs.
1 “At Frequency”
(Default)
Drive reaches commanded frequency.
2 “MotorRunning” Motor is receiving power from the drive.
3 “Hand Active” Active when drive is in local control.
4 “Motor Overld” Motor overload condition exists.
5 “Ramp Reg” Ramp regulator is modifying the programmed accel/decel
times to avoid an overcurrent or overvoltage fault from
occurring.
6 “Above Freq” • Drive exceeds the frequency (Hz) value set in T066
[Opto
Out Level].
• Use T066 to set threshold.
7 “Above Cur” • Drive exceeds the current (% Amps) value set in T066
[Opto Out Level].
• Use T066 to set threshold.
Important: Value for T066
[Opto Out Level] must be entered
in percent of drive rated output current.
8 “Above DCVolt” • Drive exceeds the DC bus voltage value set in T066
[Opto
Out Level].
• Use T066 to set threshold.
9 “Above Anlg 2” • Analog input voltage (I/O Terminal 17) exceeds the value
set in T066
[Opto Out Level].
• Do not use if T073
[Analog In 2 Sel] is set to 3 “Voltage
Mode - Bipolar”.
• This parameter setting can also be used to indicate a PTC
trip point when the input (I/O Terminal 17) is wired to a
PTC and external resistor.
• Use T066 to set threshold.
10 “Above PF Ang” • Power Factor angle has exceeded the value set in T066
[Opto Out Level].
• Use T066 to set threshold.
11 “Anlg In Loss” Analog input loss has occurred. Program T072
[Analog In 1
Loss] and/or T076 [Analog In 2 Loss] for desired action when
input loss occurs.
12 “ParamControl” Enables the output to be controlled over network
communications by writing to T066
[Opto Out Level].
(0 = Off, 1 = On.)
13 “Retries Exst” Value set in A163
[Auto Rstrt Tries] is exceeded.
14 “NonRec Fault” • Number of retries for A163
[Auto Rstrt Tries] is exceeded
OR
• Non-resettable fault occurs
OR
• A163
[Auto Rstrt Tries] is not enabled.
15 “Reverse” Drive is commanded to run in reverse direction.
16 “Logic In 1” An input is programmed as “Logic In 1” and is active.
17 “Logic In 2” An input is programmed as “Logic In 2” and is active.

Allen-Bradley PowerFlex400 Specifications

General

Enclosure	NEMA/UL Type 4/4X
Control Method	Volts per Hertz, Sensorless Vector Control
Communication	RS485
Output Voltage	0 to Input Voltage
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short Circuit, Ground Fault
Storage Temperature	-40°C to 70°C (-40°F to 158 °F)
Humidity	5...95% noncondensing
Altitude	Up to 1000m (3280ft) without derating
Input Voltage	200-240VAC, 380-480VAC, 500-600VAC, 600-690VAC (depending on model)
