Allen-Bradley PowerFlex400 User Manual

Supplemental Drive Information A-7
Figure A.1 Frame C, D, and E Connections
Figure A.2 Frame F Connections
Note: UL Approval pending for Single-Phase operation.
Input Power Connections
Input Protection
Three Phase Input
T
S
R
Input Protection
Single Phase Input
T
S
R
Input Protection
Three Phase Input
T
S
R
Input Protection
Single Phase Input
T
S
R
