A-6 Supplemental Drive Information

PowerFlex 400 Watts Loss (Rated Load, Speed & PWM)

Voltage kW (HP)

Panel Mount Watts Flange Mount Watts

Total External Internal Total

200-240V AC 2.2 (3.0) 146 119 28 146

3.7 (5.0) 207 174 33 207

5.5 (7.5) 266 228 39 266

7.5 (10) 359 315 44 359

11 (15) 488 – – –

15 (20) 650 – – –

18.5 (25) 734 – – –

22 (30) 778 – – –

30 (40) 1055 – – –

37 (50) 1200 – – –

380-480V AC 2.2 (3.0) 105 77 28 105

4.0 (5.0) 171 143 28 171

5.5 (7.5) 200 161 39 200

7.5 (10) 267 229 39 267

11 (15) 329 285 44 329

15 (20) 435 380 55 435

18.5 (25) 606 – – –

22 (30) 738 – – –

30 (40) 664 – – –

37 (50) 1019 – – –

45 (60) 1245 – – –

55 (75) 1487 – – –

75 (100) 2043 – – –

90 (125) 2617 – – –

110 (150) 3601 – – –
