Allen-Bradley PowerFlex400 User Manual

Metasys N2 F-3
Network Points
Table F.7 Binary Inputs
Network Point
Name Description ON (“1”) OFF (“0”)
Type
(NPT)
Address
(NPA)
BI 1 Ready Logic Status bit 00 Ready Not Ready
BI 2 Active Logic Status bit 01 Active Not Active
BI 3 Cmd Dir Logic Status bit 02 Forward Reverse
BI 4 Act Dir Logic Status bit 03 Forward Reverse
BI 5 Accel Logic Status bit 04 Accelerating Not Accelerating
BI 6 Decel Logic Status bit 05 Decelerating Not Decelerating
BI 7 Alarm Logic Status bit 06 Alarm No Alarm
BI 8 Fault Logic Status bit 07 Fault No Fault
BI 9 At Speed Logic Status bit 08 At Reference Not at Reference
BI 10 Main Freq Logic Status bit 09 Comm Controlled Not Comm Controlled
BI 11 Oper Cmd Logic Status bit 10 Comm Controlled Not Comm Controlled
BI 12 Param Lock Logic Status bit 11 Locked Not Locked
BI 13 Digital In 1 Logic Status bit 12
(Drive Terminal #2)
On Off
BI 14 Digital In 2 Logic Status bit 13
(Drive Terminal #3)
On Off
BI 15 Digital In 3 Logic Status bit 14
(Drive Terminal #4)
On Off
BI 16 Digital In 4 Logic Status bit 15
(Drive Terminal #5)
On Off
BI 17 Digital In 5 Drive Terminal #6 On Off
BI 18 Digital In 6 Drive Terminal #7 On Off
BI 19 Digital In 7 Drive Terminal #8 On Off
Table F.8 Analog Inputs
Network Point
Name Description Units Min/Max
Type
(NPT)
Address
(NPA)
AI 1 Feedback Feedback % 0/100
AI 2 Speed d323 [Output RPM] RPM 0/24000
AI 3 Current b003 [Output Current] A 0.00/Rated × 2
AI 4 DC Bus Volts b005 [DC Bus Voltage] V 0/820
AI 5 Last Fault b307 [Fault 1 Code] 1 1/100
AI 6 2nd Fault b308 [Fault 2 Code] 1 1/100
AI 7 Analog In 1 Drive Analog Input #1 (Drive Terminal #13) % –
AI 8 Analog In 2 Drive Analog Input #2 (Drive Terminal #17) % –
AI 9 Read Value Read value of Param. selected by AO 10
Varies by the parameter
selected.
AI 10 User In 1 User-defined Input 1
(Param. selected via ADI 1)
AI 11 User In 2 User-defined Input 2
(Param. selected via ADI 2)
AI 12 User In 3 User-defined Input 3
(Param. selected via ADI 3)
AI 13 User In 4 User-defined Input 4
(Param. selected via ADI 4)
