Allen-Bradley PowerFlex400 User Manual

A-2 Supplemental Drive Information
Specifications
Drive Ratings
Catalog Number
Output Ratings Input Ratings Branch Circuit Protection
kW (HP)
Amps
Voltage
Range kVA Amps Fuses
140M Motor
Protectors
(1)
Contactors45°C 50°C
200 - 240V AC – 3-Phase Input, 0 - 230V 3-Phase Output
22C-B012N103 2.2 (3.0) 12 12 180-265 6.5 15.5 20 140M-F8E-C16 100-C23
22C-B017N103 3.7 (5.0) 17.5 17.5 180-265 8.8 21 30 140M-F8E-C25 100-C37
22C-B024N103 5.5 (7.5) 24 24 180-265 10.9 26.1 35 140M-F8E-C32 100-C37
22C-B033N103 7.5 (10) 33 33 180-265 14.4 34.6 45 140M-F8E-C45 100-C45
22C-B049A103 11 (15) 49 49 180-265 21.3 51 70 140-CMN-6300 100-C60
22C-B065A103 15 (20) 65 65 180-265 28.3 68 90 140-CMN-9000 100-C85
22C-B075A103 18.5 (25) 75 75 180-265 32.5 78 100 140-CMN-9000 100-D95
22C-B090A103 22 (30) 90 81 180-265 38.3 92 125 – 100-D110
22C-B120A103 30 (40) 120 120 180-265 51.6 124 175 – 100-D180
22C-B145A103 37 (50) 145 130 180-265 62.4 150 200 – 100-D180
380 - 480V AC – 3-Phase Input, 0 - 460V 3-Phase Output
22C-D6P0N103 2.2 (3.0) 6 6 340-528 6.3 7.5 10 140M-D8E-C10 100-C09
22C-D010N103 4.0 (5.0) 10.5 10.5 340-528 10.9 13 20 140M-D8E-C16 100-C16
22C-D012N103 5.5 (7.5) 12 12 340-528 11.9 14.2 20 140M-D8E-C16 100-C23
22C-D017N103 7.5 (10) 17 17 340-528 15.3 18.4 25 140M-D8E-C20 100-C23
22C-D022N103 11 (15) 22 22 340-528 19.2 23 30 140M-F8E-C32 100-C30
22C-D030N103 15 (20) 30 27 340-528 25.8 31 40 140M-F8E-C32 100-C37
22C-D038A103 18.5 (25) 38 38 340-528 33.3 40 50 140M-F8E-C45 100-C60
22C-D045A103 22 (30) 45.5 45.5 340-528 39.1 47 60 140-CMN-6300 100-C60
22C-D060A103 30 (40) 60 54 340-528 53.3 64 80 140-CMN-9000 100-C85
22C-D072A103 37 (50) 72 72 340-528 60.7 73 100 140-CMN-9000 100-C85
22C-D088A103 45 (60) 88 88 340-528 74.9 90 125 – 100-D110
22C-D105A103 55 (75) 105 105 340-528 89 107 150 – 100-D140
22C-D142A103 75 (100) 142 128 340-528 124.8 150 200 – 100-D180
22C-D170A103 90 (125) 170 170 340-528 142 170 250 – 100-D250
22C-D208A103 110 (150) 208 208 340-528 167 200 250 – 100-D250
(1)
Refer to the Bulletin 140M Motor Protectors Selection Guide, publication 140M-SG001… to
determine the frame and breaking capacity required for your application.
