LTP51 H EN Safety and operating instructions
© Atlas Copco Industrial Technique AB - 9836 938172 72
7
D = 54 mm, Wmin = 28.5 mm
Torque Nm 75 100 150 200 250
Angle α 21° 27° 37° 46° 55°
LTP51 H002–20, LTP51 H004–20, LTP51 PH001–20 and LTP51 PH002–20
D = 62 mm, Wmin = 39.5 mm
Torque Nm 250 300 400 500
Angle α 30° 35° 44° 50°
LTP51 H001–25, LTP51 PH0005–25 and LTP51 H0014-25
D = 63.5 mm, Wmin = 64.5 mm
Torque Nm 500 600 700 800 950
Angle α 32° 38° 43° 47° 53°
LTP51 H0007–25 and LTP51 PH0003–25
D = 83.5 mm, Wmin = 84.5 mm
Torque Nm 700 1000 1250 1500
Angle α 21° 30° 35° 41°
Example: LTP51 H002–20
D = 62 mm
500 Nm = 50°
Maintenance
For maximum performance
It is important to lubricate regularly to get maximum performance and trouble-
free operation. The motor should be lubricated with oil; i.e. drops of oil can be
dropped either into the compressed air or directly into the air inlet.
The trigger, planetary gears, needle bearings and ball bearings should be lubri-
cated with grease during the regular overhaul of the machine.
The angle gear and clutch must be lubricated using grease that contains molyb-
denum disulphide: Molykote BR2 Plus, for example, or an equivalent brand.
Use lubricants of good quality. The oils and greases mentioned in the table are
examples of lubricants which are recommended.
Rust protection and internal cleaning
Water in the compressed air, dust and wear particles cause rust and sticking of
vanes, valves etc. An air filter should be installed close to the machine (see ‘Air
quality’).
