16 Bend-Tech Dragon A150
Troubleshooting Guide
Cutting Issues
02
Cut Rotation and Backlash Correction
An operator experiencing cut rotation issues with the Dragon A150 machine may be required to
check set screws and chains to ensure backlash settings are accurate. As a result of daily use,
the machine may experience loose set screws or chains that come out of adjustment. There is
also a Backlash Correction procedure in Bend-Tech Dragon software. Ensuring all set screws
and chains are tight and adjusted, and Backlash Correction is performed in Bend-Tech Dragon
software, will maintain cut rotation accuracy.
Tools Required
• 3mm Allen wrench
• 
• 
• ½ in. wrench
• ¾ in. wrench (2)
Symptom Cause Corrective Action
Jagged/Wavy Cuts
XCable too loose/too tight
Check X Cable; adjust tension if
necessary
Incomplete cuts
Machine moving before

Adjust dwell time in Lead In/Out
settings
Y Axis backlash out of
adjustment
Check Y Axis chain and drive sprocket
set screws
Toolhead loose
Toolhead loose on A axis
mount plate
Check Toolhead A Axis play
Trolley out of adjustment
Check Toolhead trolley play on
Toolhead rail
