57Bend-Tech Dragon A150
Troubleshooting Guide
Center Support Lift
12
12
Center Support Lift
Center Support Lift
Dragon A150 models with a 24-foot Rail come equipped with a Center Support Lift that
supports longer material, keeping it from sagging, allowing the machine to achieve accurate
operation. The Center Support Lift also relieves pressure on the Chuck, Trolley and Gate,
and assists in preventing potential Torch collision. The Center Support Lift is operated via
compressed air. It uses a mechanical push/pull switch to engage and disengage from the
material.
Symptom Cause Corrective Action
Gate moving too slow
Hinge dirty or spring worn
out
Clean Gate hinge and lubricate with
light oil
Gate not closing on
material
Gate mechanism dirty Clean gate and lubricate with light oil
Air pressure incorrect
operate the Gate mechanism
Gate mechanism worn
Inspect Gate rollers, replace if
necessary.
