CB-100-2 23
WARNING
Without the use of an external EMC filter, high-
frequency interferences will occur in the voltage
supply system!
This drive constellation is not intended for use in
a public low voltage system supplying residen-
tial areas.
Fig.14: Overview of the VARIPACK frequency inverter requirements for meeting the different EMC categories
5.5.1 Analysis of the harmonics FDU+6 .. FKU+260
Fig.15: Table for the analysis of the harmonics FDU+6 .. FEU+16
FDU+6 .. FEU+16 are classified as professionally used
device according to EN61000-3-2:2014.
