ServSwitch™ DKM
156
ServSwitch™- KVM Dual-Head, Local/ Remote Unit, with optional audio –
rear view
ServSwitch™- KVM Dual-Head, with optional audio – rear view
Connect to 5V power
supply
INTERCONNECT – carries 2
n
d
video –
Connect to Local/ Remote Unit with
CATx- cable
INTERCONNECT – carries 1
s
t
video
and data signals – Connect to Local/
Remote Unit with CATx- cable
Connect Monitor 2 to Local/
Remote Unit with Fibre cable
Connect to 5V power
supply
Connect Monitor 1, Keyboard, Mouse to
Local/ Remote Unit with Fibre cable
