ServSwitch™ DKM
16
“Control Room” Mode: As a special case of the KVM Switch, you can choose
the “Control Room” Mode. In this mode, several displays are assigned to a work
place. A comfortable OSD (On Screen Display) allows at any time to choose from a
list of available CPUs the CPU to be displayed on a specific monitor.
With a hotkey sequence, you can switch keyboard and mouse to any of these
monitors for operation without need to know the associated CPU. Now you can
operate this CPU.
Also in this mode, one (or more) display signal(s) can be copied to one or more
additional displays (“Partner Viewing”).
“Teacher/Student” System: Two configurations are available:
a) Attend up to 15 Students – Each student work place is connected by CATx-
Duplex cable. Each CPU can be displayed at any work place – both student and
teacher work place – even simultaneously. The teacher can observe every student
work place.
b) Attend up to 31 Students – Each student work place is connected by CATx-
Simplex cable. Each CPU can be displayed at a specific monitor, e.g. beamer or
large display – both student and teacher work place. The teacher can observe every
student work place.
A ServSwitch™ DKM system comprises a ServSwitch™ DKM and one or more
Local/Remote Units. The ServSwitch™ DKM and the Local/ Remote Units are attached by
CATx or Fibre interconnection cables.
The operation of a ServSwitch™ DKM requires always the use of Local Units and Remote
Units of a ServSwitch™-Extender.
