INSTALLATION
31
Fibre optical cable: Two fibres are required for Single-Head transmission and four fibres
for Dual-Head transmission.
The achievable distance depends on both the cable type and the device
type.
Recommended cables:
Multimode Type 50/125µ Achievable Distance approx. 400m (1,300ft)
Multimode Type 62.5/125µ Achievable Distance approx. 200m (650ft)
Singlemode Type 9/125µ Achievable Distance approx. 10km (32,750ft)
A point-to-point connection is required. You may use one or more patch
panels in the line. Do not connect the Fiber- link interface (LC-duplex) to
any other products, especially telecommunications or network equipment.
Empirically, Singlemode devices work well with Multimode cables but not
vice versa. Furthermore, Singlemode devices with Multimode cables might
double the achievable distance via Multimode cable! This cannot be
guaranteed, however, and must be verified by the user at own risk and cost.
Power Supply: Connect the supplied 5V/DC power supply to the ‘POWER’ socket of the
ServSwitch™ Local Unit or ServSwitch™ Remote Unit.
