Troubleshooting
11-30
Changing the P
aper Size Setting
1
Press [
Additional F
unctions].
2
Press [
] or [
] to select <P
APER SET
TINGS>, then press [
OK
].
3
Press [
] or [
] to select <CASSE
TTE> or <MP
TRA
Y>, then press [OK].
4
Press [
] or [
] to select <P
APER SIZE>, then press [
OK].
252
254
