113
Cap Threshold Adding (
Z.PLU) — This parameter is used in
the calculation of SMZ and is calculated as follows:
Z.PLU = Configuration
COOL
Z.GN * (10 + (4*
(–ADD.R))) * 0.6.
High Temp Cap Override (
H.TMP) — If stages of mechani-
cal cooling are on and the error is greater than twice Y.PLU,
and the rate of change of error is greater than 0.5F, then a
stage of mechanical cooling will be added every 30 seconds.
This override is intended to react to situations where the load
rapidly increases.
Table 84 — Economizer Run Status Display Table
Table 85 — Cooling Information Display Table
ITEM EXPANSION RANGE UNITS CCN POINT WRITE STATUS
ECON ECONOMIZER RUN STATUS
EC1.P Economzr1 Act.Curr.Pos. 0-100 % ECON1POS
EC2.P Economzr2 Act.Curr.Pos. 0-100 % ECON2POS
EC3.P Economzr3 Act.Curr.Pos. 0-100 % ECON3POS
ECN.C Economizer Act.Cmd.Pos. 0-100 % ECONOCMD forcible
ACTV Economizer Active ? YES/NO ECACTIVE
DISA ECON DISABLING CONDITIONS
UNV.1 Econ1 Act. Unavailable? YES/NO ECN1UNAV
UNV.2 Econ2 Act. Unavailable? YES/NO ECN2UNAV
UNV.2 Econ3 Act. Unavailable? YES/NO ECN3UNAV
ENTH Enth. Switch Read High ? YES/NO ENTH
DBC DBC - OAT Lockout? YES/NO DBC_STAT
DEW DEW - OA Dewpt.Lockout? YES/NO DEW_STAT
DDBC DDBD- OAT > RAT Lockout? YES/NO DDBCSTAT
OAEC OAEC- OA Enth Lockout? YES/NO OAECSTAT
DEC DEC - Diff.Enth.Lockout? YES/NO DEC_STAT
EDT EDT Sensor Bad? YES/NO EDT_STAT
OAT OAT Sensor Bad ? YES/NO OAT_STAT
FORC Economizer Forced ? YES/NO ECONFORC
SFON Supply Fan Not On 30s ? YES/NO SFONSTAT
CLOF Cool Mode Not In Effect? YES/NO COOL_OFF
OAQL OAQ Lockout in Effect ? YES/NO OAQLOCKD
HELD Econ Recovery Hold Off? YES/NO ECONHELD
DH.DS Dehumid. Disabled Econ.? YES/NO DHDISABL
O.AIR OUTSIDE AIR INFORMATION
OAT Outside Air Temperature dF OAT forcible
OA.RH Outside Air Rel. Humidity % OARH forcible
OA.E Outside Air Enthalpy OAE
OA.D.T OutsideAir Dewpoint Temp dF OADEWTMP
ITEM EXPANSION RANGE UNITS CCN POINT WRITE STATUS
COOL COOLING INFORMATION
C.CAP Current Running Capacity % CAPTOTAL
CUR.S Current Cool Stage COOL_STG
REQ.S Requested Cool Stage CL_STAGE
MAX.S
Maximum Cool Stages CLMAXSTG
DEM.L Active Demand Limit % DEM_LIM forcible
SUMZ COOL CAP. STAGE CONTROL
SMZ Capacity Load Factor -100 +100 SMZ
ADD.R Next Stage EDT Decrease ^F ADDRISE
SUB.R Next Stage EDT Increase ^F SUBRISE
R.PCT Rise Per Percent Capacity RISE_PCT
Y.MIN Cap Deadband Subtracting Y_MINUS
Y.PLU Cap Deadband Adding Y_PLUS
Z.MIN Cap Threshold Subtracting Z_MINUS
Z.PLU Cap Threshold Adding Z_PLUS
H.TMP High Temp Cap Override HI_TEMP
L.TMP Low Temp Cap Override LOW_TEMP
PULL Pull Down Cap Override PULLDOWN
SLOW Slow Change Cap Override SLO_CHNG
HMZR HUMIDIMIZER
CAPC Humidimizer Capacity HMZRCAPC
C.EXV Condenser EXV Position COND_EXV
B.EXV Bypass EXV Position BYP_EXV
RHV Humidimizer 3-Way Valve HUM3WVAL
C.CPT Cooling Control Point COOLCPNT
EDT Evaporator Discharge Tmp EDT
H.CPT Heating Control Point HEATCPNT
LAT Leaving Air Temperature LAT
EXVS EXVS INFORMATION
A1.EX Circuit A EXV 1 Position 0 to 100 % XV1APOSP
A2.EX Circuit A EXV 2 Position 0 to 100 % XV2APOSP
B1.EX Circuit B EXV 1 Position 0 to 100 % XV1BPOSP
B2.EX Circuit B EXV 2 Position 0 to 100 % XV2BPOSP
SH.A1 Cir A EXV1 Superheat Tmp –100 to 200 ^F SH_A1
SH.A2 Cir A EXV2 Superheat Tmp –100 to 200 ^F SH_A2
SH.B1 Cir B EXV1 Superheat Tmp –100 to 200 ^F SH_B1
SH.B2 Cir B EXV2 Superheat Tmp –100 to 200 ^F SH_B2
CTRL EXVS CONTROL INFORMATION
C.SHS EXV Superheat Ctrl SP 5 to 40 ^F SH_SP_CT
C.FLS EXV SH Flooding Ctrl SP 0 to 10 ^F FL_SP_CT
C.EXP EXV PID Ctrl Prop. Gain 0 to 5 EXV_PG_C
C.EXT EXV Ctrl Integrat. Time 0.5 to 60 EXV_TI_C
C.EXM Cir Strt EXV Mn Ctrl Pos EXCSMP_C
