233
APPENDIX F — BACNET COMMUNICATION OPTION (cont)
NETWORK POINTS LIST (cont)
LEGEND
POINT DESCRIPTION CCN POINT NAME
READ/
WRITE
UNITS
DEFAULT
VALUE
RANGE
BACNET
OBJECT ID
BACNET
OBJECT NAME
UV-C Lamp UVC_LAMP R BV:84 uvc_lamp_1
UV-C Lamp Status UVCSTS R BV:85 uvcsts_1
VAV Occ. Cool Off Delta VAVOCOFF R/W °^F 1 - 25 AV:180 vavocoff_1
VAV Occ. Cool On Delta VAVOCON R/W °^F 0 - 25 AV:181 vavocon_1
Vent Reheat RAT Offset DHVRAOFF R/W °^F 0 0 - 8 AV:183 dhvraoff_1
Vent Reheat Setpoint DHVHT_SP R/W °F 70 55 - 95 AV:184 dhvht_sp_1
VFD Maximum Speed STATPMAX R/W % 100 0 - 100 AV:188 statpmax_1
VFD Minimum Speed STATPMIN R/W % 20 0 - 100 AV:189 statpmin_1
VFD/Act. Fire Speed/Pos. BLDGPFSO R/W % 100 0 - 100 AV:186 bldgpfso_1
VFD/Act. Min. Speed/Pos. BLDGPMIN R/W % 0 0 - 100 AV:105 bldgpmin_1
VFD1 Actual Motor Amps VFD1AMPS R A 0 - 999 AV:79 vfd1amps_1
VFD1 Actual Motor Freq VFD1FREQ R 0 - 500 AV:80 vfd1freq_1
VFD1 Actual Motor Power VFD1PWR R kW AV:81 vfd1pwr_1
VFD1 Actual Motor RPM VFD1RPM R 0 - 30000 AV:82 vfd1rpm_1
VFD1 Cumulative kWh VFD1KWH R 0 - 65535 AV:84 vfd1kwh_1
VFD1 Cumulative Run Time
VFD1RUNT R hr 0 - 65535 AV:86 vfd1runt_1
VFD1 DC Bus Voltage VFD1VDC R V 0 - 1000 AV:87 vfd1vdc_1
VFD1 Last Fault Code
VFD1LFC R 0 - 65535 AV:88 vfd1lfc_1
VFD1 Output Voltage VFD1VOUT R V 0 - 1000 AV:89 vfd1vout_1
VFD1 Status Word 1 VFD1STAT R 0 - 0 AV:90 vfd1stat_1
VFD1 Transistor Temp (C)
VFD1TEMP R 0 - 150 AV:91 vfd1temp_1
VFD2 Actual Motor Amps VFD2AMPS R A 0 - 999 AV:92 vfd2amps_1
VFD2 Actual Motor Freq VFD2FREQ R 10 - 500 AV:93 vfd2freq_1
VFD2 Actual Motor Power VFD2PWR R AV:94 vfd2pwr_1
VFD2 Actual Motor RPM VFD2RPM R AV:95 vfd2rpm_1
VFD2 Cumulative kWh
VFD2KWH R AV:96 vfd2kwh_1
VFD2 Cumulative Run Time VFD2RUNT R hr AV:97 vfd2runt_1
VFD2 DC Bus Voltage VFD2VDC R V AV:99 vfd2vdc_1
VFD2 Last Fault Code
VFD2LFC R AV:100 vfd2lfc_1
VFD2 Output Voltage VFD2VOUT R V AV:102 vfd2vout_1
VFD2 Status Word 1
VFD2STAT R AV:103 vfd2stat_1
VFD2 Transistor Temp (C) VFD2TEMP R AV:104 vfd2temp_1
VFD-IGV Fire Speed Override STATPFSO R/W % 100 0 - 100 AV:187 statpfso_1
Zone Temp/Override Time Re-
maining
OVERRIDE_TIME_
REMAINING R AV:1 override_time_remaining_1
BP — Building Pressure
DBC — Dry Bulb Changeover
DCV — Demand Control Ventilation
DDBC — Differential Dry Bulb Changeover
DEC — Differential Enthalpy Changeover
DEW — Dewpoint
EDT — Evaporator Discharge Temperature
EXV — Electronic Expansion Valve
IAQ — Indoor Air Quality
IGC — Integrated Gas Control
LAT — Leaving Air Temperature
n/a — Not Available
OAEC — Outdoor Air Enthalpy Changeover
OAT — Outdoor Air Temperature
OAQ — Outdoor Air Quality
R—Read
RAT — Return Air Temperature
RH — Relative Humidity
SASP — Supply Air Set Point
SP — Setpoint
SPT — Space Temperature
VAV — Variable Air Volume
VFD — Variable Frequency Drive
W—Write
