208
APPENDIX C — UNIT STAGING TABLES
TIME SCHEDULE CONFIG TABLE
Allowable Entries: Day not selected = 0 Day selected = 1
UNIT SIZE N STAGING SEQUENCE WITH MLV (75 TON NOMINAL CAPACITY)
*Minimum load valve (MLV). MLV is enabled on Circuit A when
decreasing from stage 1 to stage 0 to provide an increased stage of
capacity.
UNIT SIZE N STAGING SEQUENCE WITH DIGITAL COMPRESSOR (75 TON NOMINAL CAPACITY)
UNIT SIZE N STAGING SEQUENCE WITHOUT MLV (75 TON NOMINAL CAPACITY)
DAY FLAGS
MTWTFSSH
OCCUPIED
TIME
UNOCCUPIED
TIME
Period 1:
00000000 00:00 00:00
Period 2:
00000000 00:00 00:00
Period 3:
00000000 00:00 00:00
Period 4:
00000000 00:00 00:00
Period 5:
00000000 00:00 00:00
Period 6:
00000000 00:00 00:00
Period 7:
00000000 00:00 00:00
Period 8:
00000000 00:00 00:00
STAGE
SEQUENCE
01*12345
COMP Compressor Status
A1 OFFONONONONONON
A2 OFF OFF OFF OFF ON ON ON
B1 OFF OFF OFF ON ON ON ON
B2 OFF OFF OFF OFF OFF ON ON
B3 OFF OFF OFF OFF OFF OFF ON
UNIT Total Capacity
075 0% 18% 23% 41% 65% 82% 100%
STAGE
SEQUENCE
012345
COMP Compressor Status
A1 OFFONONONONON
A2 OFFOFFOFFONONON
B1 OFF OFF ON ON ON ON
B2 OFF OFF OFF OFF ON ON
B3 OFF OFF OFF OFF OFF ON
UNIT Total Capacity
075 0% 12% to 23% 29% to 41% 53% to 65% 71% to 82% 88% to 100%
STAGE
SEQUENCE
0123456
COMP Compressor Status
A1 OFF OFF ON ON ON ON ON
A2 OFF OFF OFF OFF ON ON ON
B1 OFF ON OFF ON ON ON ON
B2 OFF OFF OFF OFF OFF ON ON
B3 OFF OFF OFF OFF OFF OFF ON
UNIT Total Capacity
075 0% 18% 23% 41% 65% 82% 100%
