CL-5
CONTROLS SET POINT AND CONFIGURATION LOG (cont)
ITEM EXPANSION RANGE DEFAULT SETTING
BP (CONT)
DMD.L DEMAND LIMIT CONFIG.
DMD.LDM.L.S Demand Limit Select 0 to 3 (multi-text strings) 0
DMD.LD.L.20 Demand Limit at 20 ma 0 to 100 % 100
DMD.LSH.NM Loadshed Group Number 0 to 99 0
DMD.LSH.DL Loadshed Demand Delta 0 to 60 % 0
DMD.LSH.TM Maximum Loadshed Time 0 to 120 min 6
DMD.LD.L.S1 Demand Limit Sw.1 Setpt. 0 to 100 % 80
DMD.LD.L.S2 Demand Limit Sw.2 Setpt. 0 to 100 % 50
IAQ INDOOR AIR QUALITY CFG.
DCV.C DCV ECONOMIZER SETPOINTS
DCV.CEC.MN Economizer Min.Position 0 to 100 % 5
DCV.CIAQ.M IAQ Demand Vent Min.Pos. 0 to 100 % 0
DCV.CO.C.MX Economizer Min.Flow 0 to 20000 cfm 2000
DCV.CO.C.MN IAQ Demand Vent Min.Flow 0 to 20000 cfm 0
DCV.CO.C.DB Econ.Min.Flow Deadband 200 to 1000 cfm 400
AQ.CF AIR QUALITY CONFIGS
AQ.CFIQ.A.C IAQ Analog Sensor Config 0 to 4 (multi-text strings) 0
AQ.CFIQ.A.F IAQ 4-20 ma Fan Config 0 to 2 (multi-text strings) 0
AQ.CFIQ.I.C IAQ Discrete Input Confg 0 to 2 (multi-text strings) 0
AQ.CFIQ.I.F IAQ Disc.In. Fan Config 0 to 2 (multi-text strings) 0
AQ.CFOQ.A.C OAQ 4-20ma Sensor Config 0 to 2 (multi-text strings) 0
AQ.SP AIR QUALITY SETPOINTS

AQ.SPIQ.O.P IAQ Econo Override Pos. 0 to 100 % 100
AQ.SPIQ.O.C IAQ Override Flow 0 to 31000 cfm 10000
AQ.SPDAQ.L Diff.Air Quality LoLimit 0 to 1000 100
AQ.SPDAQ.H Diff.Air Quality HiLimit 100 to 2000 700
AQ.SPD.F.OF DAQ PPM Fan Off Setpoint 0 to 2000 200
AQ.SPD.F.OM DAQ PPM Fan On Setpoint 0 to 2000 400
AQ.SPIAQ.R Diff. AQ Responsiveness -5 to 5 0
AQ.SPOAQ.L OAQ Lockout Value 0 to 2000 0
AQ.SPOAQ.U User determined OAQ 0 to 5000 400
AQ.SR AIR QUALITY SENSOR RANGE
AQ.SRIQ.R.L IAQ Low Reference 0 to 5000 0
AQ.SRIQ.R.H IAQ High Reference 0 to 5000 2000
AQ.SROQ.R.L OAQ Low Reference 0 to 5000 0
AQ.SROQ.R.H OAQ High Reference 0 to 5000 2000
IQ.PQ IAQ PRE-OCCUPIED PURGE
IQ.PQIQ.PQ IAQ Purge No/Yes No
IQ.PQIQ.P.T IAQ Purge Duration 5 to 60 min 15
IQ.PQIQ.P.L IAQ Purge LoTemp Min Pos 0 to 100 % 10
IQ.PQIQ.P.H IAQ Purge HiTemp Min Pos 0 to 100 % 35
IQ.PQIQ.L.O IAQ Purge OAT Lockout 35 to 70 dF 50
HUMD HUMIDITY CONFIGURATION
HUMD
HM.CF Humidifier Control Cfg. 0 to 4 0
HUMDHM.SP Humidifier Setpoint 0 to 100 % 40
H.PID HUMIDIFIER PID CONFIGS
H.PIDHM.TM Humidifier PID Run Rate 10 to 120 sec 30
H.PIDHM.P Humidifier Prop. Gain 0 to 5 1
H.PIDHM.I Humidifier Integral Gain 0 to 5 0.3
H.PIDHM.D Humidifier Deriv. Gain 0 to 5 0.3
ACT.C HUMIDIFIER ACTUATOR CFGS
ACT.CSN.1 Humd Serial Number 1 0 to 9999 0
ACT.CSN.2 Humd Serial Number 2 0 to 6 0
ACT.CSN.3 Humd Serial Number 3 0 to 9999 0
ACT.CSN.4 Humd Serial Number 4 0 to 254 0
ACT.CC.A.LM Humd Ctrl Angle Lo Limit 0 to 90 85
DEHU DEHUMIDIFICATION CONFIG.
DEHUD.SEL Dehumidification Config 0 to 5 (multi-text strings) 0
DEHUD.SEN Dehumidification Sensor 1 to 3 (multi-text strings) 1
DEHUD.EC.D Econ disable in DH mode? No/Yes Yes
DEHUD.V.CF Vent Reheat Setpt Select 0 to 1 (multi-text strings) 0
DEHUD.V.RA Vent Reheat RAT offset 0 to 8 ^F 0
DEHUD.V.HT Vent Reheat Setpoint 55 to 95 dF 70
DEHUD.C.SP Dehumidify Cool Setpoint 40 to 55 dF 45
DEHUD.RH.S Dehumidify RH Setpoint 10 to 90 % 55
DEHUH.SEL Heat Reclaim Config 0 to 2 0
DEHUHZ.RT HumidiMizer Adjust Rate 5 to 120 sec 30
DEHUHZ.PG HumidiMizer Prop. Gain 0 to 10 0.8
