TOWING THE TRUCK
The standard fork lift trucks are not suited for towing.
In special case, the rear draw bar can be used to tow a faulty
lift truck.
In this case it is obligatory to use a stiff towing bar, fastened
between the rear draw bar of the truck and the towing
vehicle. You must proceed carefully and slowly, if possible on
a level surface.
• while towing, do not carry any other loads on the forks;
• as far as possible, avoid driving on gradients. In any case,
do not go over the figure for driving on gradients with a
load.
Note the cautions below when towing the vehicle with
back wheels lifted.
• Lift the rear wheels for towing
• The traveling speed when towing must not exceed the
maximum traveling speed of the forklift
• Before starting towing, always set the key switch to OFF,
the direction switch to the neutral position and parking
brake of released
• Before towing, either remove the fork or take action to
prevent the fork from coming into contact with the ground
due to bouncing
When making a curve, towed loads tend to reduce the
curving radius; therefore it is important to widen the entrance
radius in order to avoid striking against any obstacle.
