CESAB B 215 User Manual

2-28
FUSE 24 VOLT
This fuse box is situated under the dashboard and feeds only the optional equipments.
1. J90 connector for auxiliary wiring feeding
2. Feeding fuses positive connection bars
3. Connector for direction indicator intermittence
J90 = 24V FUSES CONNECTOR
1
2
3
Fuses Capacity (A) Wire colour Destination
FA (1)
FB (2)
FC (3)
FD (4)
FE (5)
FF (6)
FG (7)
FH (8)
FI (9)
FL (10)
FM(11)
7.5 A
5 A
7.5 A
5 A
7.5 A
7.5 A
7.5 A
5 A
orange
yellow
purple
pink
black/blue
green
white
orange/white
unused
direction lights
rotating beacon
front and rear wiper
Directionindicator
heating
front and rear window
defroster
work spotlights
unused
car radio
unused
Pin Wire Description Standard
1 red Fuses supply + 24V
2 red-orange Dimmed headlights + overall lights + 24V
3 red-light blue Left direction light + 24V
4 red-grey Right direction light + 24V
5 − Unused −
6 − Unused −
7 blue Negative GND
8 brown Unused −
J90
1
2
3
4
56
7
8
1
2
34
56
7
8
910
11
J90
