CESAB B 215 User Manual

2-30
ADJUSTING THE FOOT BRAKE SWITCH
1. Adjust the brake pedal play (approx. 1mm).
2. Adjust brake rod length.
3. Check the continuity of the speed reduction switch
Standard: Not operated: OFF (∞ Ω )
operated: ON (0 Ω )
4. Check that the microswitch for the regenerative brake
turns ON (OFF) when the brake pedal is depressed
from the neutral position without any play.
Standard: Not operated: OFF (0 Ω )
operated: ON (∞ Ω )
5. If the standard is not met, adjust the microswitch
position.
PARKING BRAKE SWITCH ADJUSTMENT
1. Check the ON/OFF operation of the parking brake limit
switch
Standard: Lever returned to original position:
ON (0 Ω )
Lever pulled: OFF (∞ Ω )
2. If the standard is not met, adjust the microswitch
installation location.
Approximately 1mm
Brake pedal play in neutral position
