Chapter 9 Removal and Replacement Procedures
Removing and Replacing the Optical Bypass Module
Removing a SPA from a SIP
To remove a SPA from a SIP, refer toFigure 9-17 and do the following:
Step 1 At the SCE# prompt, type reload shutdown and press Enter to power down the Cisco SCE8000
platform before installing or removing any module.
Step 2 If attached, remove any cables from the SPA.
Step 3 To remove the SPA from the SIP, unfasten the captive installation screws on the SPA.
Step 4 Grasp the handles of the SPA and pull the SPA from the SIP.
Removing and Replacing the Optical Bypass Module
• Removing the Optical Bypass Module, page 9-26
• Installing the Optical Bypass Module, page 9-26
• Replacing the Optical Bypass Module without Disrupting Traffic on the Link, page 9-27
Removing the Optical Bypass Module
Step 1 Disconnect all cables.
Step 2 Loosen the two captive screws on the module.
Step 3 Pull the module out of the slot. Place your other hand under the module to support the weight of the
module. Do not touch the module circuitry.
Step 4 Place the module on antistatic foam, or immediately reinstall it in another slot.
Step 5 If the slot is to remain empty, install a module filler plate to keep dust out of the chassis and to maintain
proper airflow through the chassis.
Installing the Optical Bypass Module
Step 1 Remove the module filler plate by loosening the two screws.
Step 2 Insert the module into the opening in the panel. There are no guide rails. Do not touch the module
circuitry.
Step 3 Tighten the two captive screws on the module.
Step 4 Connect the cables as described in Cabling the 10GBE Line Interface Ports: Using the External Optical
Bypass Module, page 6-11.
