Cisco SCE8000 Installation And Configuration Guide

5-4
Cisco SCE8000 Installation and Configuration Guide, Rel 3.1.7
OL-16478-03
Chapter 5 Connecting the Management Interfaces
Connecting the Management Interface
Connecting the Management Interface
The SCE8000-SCM-E is equipped with one active RJ-45 management port. This port provides access
from a remote management console to the Cisco SCE8000 via a LAN.
The procedures for cabling the GBE management port and testing connectivity between the Cisco
SCE8000 and the remote management host are explained in the following sections.
• How to Cable the Management Port, page 5-4
• How to Verify Management Interface Connectivity, page 5-5
How to Cable the Management Port
The SCE8000-SCM-E has one GBE port that is used as the management port, located in slot# 1 of the
Cisco SCE8000 chassis, and labeled Port1.
Step 1 Plug the Ethernet cable provided (with attached RJ-45 connector) into Port 1on the front panel of the
SCE8000-SCM-E. (See item #3 in Figure 5-3 below.)
Figure 5-3 Cabling the Management Port
Domain name server show hosts ip domain-lookup
ip domain-name domain-name
ip name-server server-address1
[server-address2] [server-address3]
Global Configuration
RDR formatter
destination
show rdr-formatter destination rdr-formatter destination
ip-address port port-number
Global Configuration
Figure 5-2 Initial Setup Configuration (continued)
Parameter show command configuration command
configuration command
mode
270976
S
CE8000-SCM-E
1
0/
1
00/
1
00
0
L
INK
/
AC
T
IVE
O
PT
IC
A
L
B
YPASS1
C
ONS
OLE
PORT1
1
2
3
