Chapter 4 Installing the Cisco SCE8000 Chassis
Site Planning Checklist
Note The DC supplies each have the provision for a dual connection to the power source in order to permit
high-power operation without exceeding current ratings. For the SCE 8000, it is not necessary to connect
both of these inputs to DC power sources; it is sufficient to connect only the '1' connections.
Site Planning Checklist
Table 2-6 lists the site planning activities that you should perform prior to installing the Cisco SCE8000
chassis. Completing each activity helps ensure a successful installation.
DC-input cable Accepts 2-14 AWG copper conductors. Actual size of the wire
needed is determined by the installer or local electrician.
Terminal block material rated at 150°C.
DC-input circuit breaker For multiple DC input power supplies, each DC input must be
protected by a dedicated two-pole circuit breaker or a fuse.
The circuit breaker or the fuse must be sized according to the power
supply input power rating and any local or national electrical code
requirements.
Table 4-5 Cisco SCE 8000 DC Power Supply Specification (continued)
Specification Acceptable Range
Table 4-6 Site Planning Checklist
Task No. Planning Activity Verified By Time Date
1 Space evaluation:
Space and layout
Floor covering
Impact and vibration
Lighting
Maintenance access
2 Environmental evaluation:
Ambient temperature
Humidity
Altitude
Atmospheric contamination
Airflow
