310-0510 IHT
15
Operation U.S. Torque Metric Torque Item Description
Side Housing Screws 105-155 lb-in 12-17 Nm 7 Screw ¼-20 x 1.25
Housing Stud 230-310 lb-in 26-35 Nm 8 Stud 5/16-24 Hex
Control Arm Screw 230-310 lb-in 26-35 Nm 16 Screw 5/16-24 x 0.75
Check Plugs 280-400 lb-in 32-45 Nm 23/75 Check Plug Assembly
Center Section Bolts 525-700 lb-in 60-80 Nm 44 Screw 3/8-24 x 2.5
Brake Yoke Bolt 80-120 lb-in 9-14 Nm 63 HFHCS ¼-20 x 2
Brake Yoke Bolt 80-120 lb-in 9-14 Nm 64 Bolt ¼-20 x 1
Friction Pack Mounting Stud 50-120 lb-in 6-14 Nm 76 Stud 5/16-24
Friction Pack Nut 85-120 lb-in 10-14 Nm 80 Lock Nut 5/16-24
Expansion Tank Hose Fitting 96-120 lb-in 11-14 Nm 84 Fitting 5/16 SAE 5/32 Tube
Belt Keeper Screw 40-70 lb-in 5-8 Nm 88 Screw, Self-Tapping 10-32 x .5
Bracket Support Bolt 42-65 lb-in 5-7 Nm 88 Bolt 10-32 x 0.5
Friction Pack Wedge Screw 30-70 in-lb 3.4-8 Nm 88 Screw, Self Tapping 10-32 x .5
Puck Inner Wedge Bolt 42-65 lb-in 5-7 Nm 88 Bolt 10-32 x 0.5
Adjusting Puck Screw 250-320 lb-in 28-36 Nm 95 Socket Hd CS 5/16-24 x 1.50
RTN Screw 180-240 lb-in 20-27 Nm 97 Screw, Countersunk 5/16-18 x 1
Bracket Screw 230-310 lb-in 26-35 Nm 110 Screw, Torx Hd 5/16-18 x 1.50
Fan/Pulley-Input Shaft Nut 300-460 lb-in 34-52 Nm 121 Nut, Hex Lock ½-20 w/nylon
Fan/Pulley Screws 65-90 lb-in 8-10 Nm 122 Screw, Hex Flange ¼-20 x .75
Fan/Pulley Nuts 35-50 lb-in 4-6 Nm 124 Nut, Hex ¼-20
Cruise Damper Bracket Nuts 160-210 lb-in 18-24 Nm 132 Nut, Hex 5/16-18
Axle Hub Nut 180-200 lb-ft 244-271 Nm 152 Nut, Hex Lock 3/4-16
Table 5. Required Torque Values
Miscellaneous
310-0510 Service & Repair Manual
Flat Blade Screw Driver (2)
Torque Wrench
Air Impact Wrench
Rubber Mallet
Breaker Bar
Side Cutters/Snips
Pliers
Needle Nose
Large External Snap Ring
Sockets
1/2"- 3/8" Adapter
1/2" Deep
7/16" Deep
9/16" Deep
3/4" Deep
7/8"
10 mm
T-25 Torx Head
Table 4. Required Tools
TOOLS AND TORQUES
