Daikin LXE10E-A User Manual

Pressure Out put
(kPa  G) (V)
– 500 – 1.03
– 400 – 0.72
– 300 – 0.42
– 200 – 0.11
– 100 0.19
0 0.50
100 0.81
200 1.11
300 1.42
400 1.72
500 2.03
600 2.34
700 2.64
800 2.95
900 3.25
1000 3.56
7-4
7.7 Temperature conversion table and temperature sensor (DCHS)
characteristics table
Temperature(
°C)
Temperature(
°F)
Resistance(kΩ) Temperature(
°C)
Temperature(
°F)
Resistance(kΩ)
72 162 32.783 102 216 12.566
74 165 30.629 104 219 11.835
76 169 28.635 106 223 11.153
78 172 26.787 108 226 10.515
80 176 25.073 110 230 9.919
82 180 23.482 112 234 9.361
84 183 22.005 114 237 8.840
86 187 20.633 116 241 8.351
88 190 19.358 118 244 7.894
90 194 18.171 120 248 7.465
92 198 17.066 122 252 7.063
94 201 16.037 124 255 6.685
96 205 15.078 126 258 6.331
98 208 14.184 128 262 5.998
100 212 13.350 130 266 5.686
7.8 High pressure transducer
characteristics table
Pressure Out put Pressure Out put
(kPa  G) (V) (kPa  G) (V)
0 0.50 1100 1.62
100 0.60 1200 1.72
200 0.70 1300 1.83
300 0.81 1400 1.93
400 0.91 1500 2.03
500 1.01 1600 2.13
600 1.11 1700 2.23
700 1.21 1800 2.34
800 1.32 1900 2.44
900 1.42 2000 2.54
1000 1.52 2100 2.64
7.9 Low pressure transducer
characteristics table
07LXE10E-A(1-8)07.2.194:58PMページ7-4
https://daikin-p.ru

Daikin LXE10E-A Specifications

General

Brand	Daikin
Model	LXE10E-A
Category	Air Conditioner
Language	English

Summary

SAFETY PRECAUTIONS

DANGER

Critical safety warnings regarding high voltage and immediate hazards.

WARNING

Important safety precautions to prevent severe personal injury or equipment damage.

CAUTION

Precautions to prevent minor injury or equipment damage during operation.

1. INTRODUCTION

1.1 Operation range

Specifies the ambient and internal temperature, voltage, and shock limits for unit operation.

1.2 Basic names of components

Identifies key external components of the refrigeration unit with labels and descriptions.

1.3 Basic operation of refrigeration unit

Details the fundamental steps for starting, checking, and shutting down the refrigeration unit.

2. GENERAL DESCRIPTION

2.1 Main specifications

Lists the technical specifications of the LXE10E model, including cooling system, power, and components.

2.5 Operation modes and control

Explains the different operational modes like Chilled, Frozen, Partial Frozen, and Defrosting.

3. ELECTRONIC CONTROLLER

3.2 Basic operation of electronic controller

Describes the control panel layout, LEDs, LCD, and operation keys for the electronic controller.

3.3 Operation procedure

Outlines the sequence of operations for accessing various modes and functions of the controller.

3.4 Alarm display and back-up function

Lists and explains alarm codes, their causes, and backup operations for sensor malfunctions.

4. SERVICE AND MAINTENANCE

4.1 Maintenance service

Covers essential maintenance tasks like refrigerant handling and gauge manifold usage.

4.2 Main components and maintenance

Provides detailed procedures for replacing major components like compressors and fans.

6. TROUBLESHOOTING

6.1 Refrigeration system and electrical system

Provides a systematic guide to diagnose and resolve issues related to the refrigeration and electrical systems.

6.2 Alarm codes on electronic controller

Lists and explains alarm codes generated by the electronic controller, including possible causes.

6.5 Emergency operation

Details procedures for emergency operation of the controller and its components.

7. APPENDIX

7.1 Standard tightening torques for bolts

Lists standard tightening torques for various bolts used in the unit assembly.

7.10 Piping diagram

Illustrates the refrigerant piping layout of the LXE10E unit, showing component connections.

7.13 Schematic wiring diagram (Connector type terminal board and rechargeable battery)

Shows the electrical wiring connections for the controller, recorder, and battery using connector types.

8. OPTIONAL FUNCTIONS MANUAL

8.1 Electronic temperature recorder

Details the standard type electronic temperature recorder, its specifications, and operation.

8.2 Electronic controller

Explains special operations, modes, and settings for the electronic controller.

8.4 USDA transportation

Outlines requirements and procedures for USDA transportation, including sensor types and calibration.
