●Operation panel
(Outside of the control box)
●Inside of the control box
2
3
1
3
1
2
b
–12 –10 –8 –6 –4 –2
–2–3–4–5–6 –1
SP–5
OVER
2
INRANGE
HOURS
DAYS
1
UNDER
ALARM
R.H.
SUPPLY
RETURN
˚C / ˚F
%R H
DEFROST INRANGED–HUMID
COMP.
˚C
˚C
SP+
5
DECOS
DAIKIN ELECTRONICCONTAINER OPERATION SYSTEM
DOWN RNTER / ESCUP
SET
DISPLAYSELECT
ON / OFF
UNIT
S
MODE
DEFROST
MANUAL
SELECT
15
4 5 76 8 9
20 12 10
22
17
16
19
18
21 1113
14
2.2.3 Control box
q Controller operation panel (EC3, 4)
w MANUAL DEFROST key
e UNIT ON/OFF key
r Phase correction contactor (PCC1,2)
t Magnetic contactor for high speed evaporator fan (EFH)
y Magnetic contactor for low speed evaporator fan (EFL)
u Magnetic contactor condenser fan (CFC)
i Reverse phase protection device (RPP)
o Adopter PCB (EC6)
!0 Terminal block board (TB1)
!1 Controller CPU / IO board (EC1, 2)
!2 Fuse (Fu1-6)
!3 Battery (BAT)
!4 Remote monitoring receptacle (RM) (optional)
!5 Personal computer receptacle
!6 Circuit breaker (CB)
!7 PT/CT board
!8 Transformer (TrC), control circuit
!9 Magnetic contactor for compressor (CC)
@0 P.C.B for humidity sensor (HUS, optional)
@1 Modem (RCD, optional)
@2 Noise filter (NF, optional)
