Page #124 background image
1
2
3
3
1 2 1 2
xR12L
xR10L
e30bl552.10
Figure 124: Inlet and Outlet Connectors of System Modules with Integration Units xR10L and xR12L
1 Outlet connectors 2 Inlet connectors
3 Optional outlet connectors
2
1
e30bj144.10
Figure 125: Inlet and Outlet Connectors of the L Filter
1 Inlet/outlet connector 2 Inlet/outlet connector
9.7.2 Draining the Power Units for xR10L and xR12L
Always drain the power units before storage or transportation.
Required for the draining procedure:
l Tools for opening the quick-release connectors of the coolant inlet and outlet.
124 | Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A
Design Guide | iC7 Series Liquid-cooled System Modules
