Danfoss iC7 Series Design Guide

234
(9.21)
212.5
(8.37)
79.5
(3.13)
67.5
(2.66)
20
(0.79)
20
(0.79)
20
(0.79)
11
(0.43)
6
(0.24)
Ø5
(0.2)
16.5
(0.65)
3.5
(0.14)
1.25
(0.05)
32.5
(1.28)
22
(0.87)
41.5
(1.63)
67.5
(2.66)
6
(0.24)
11
(0.43)
Ø5
(0.2)
63
(2.48)
63
(2.48)
75.5
(2.97)
e30bi576.11
Figure 146: Dimensions of the Modular Control Unit Mounting Plate in mm (in), 4 Places
10.2.20 Dimensions of the Option Connector
19.9
(0.78)
31.1
(1.22)
13.2
(0.52)
e30bi577.11
Figure 147: Dimensions of the Option Connecto in mm (in)
146 | Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A
Design Guide | iC7 Series Liquid-cooled System Modules
