8 SOFTWARE CONFIGURATION
Software configuration of your Matrix 210™ for static reading or simple code reading
applications can be accomplished by the Rapid Configuration procedure using the X-
PRESS™ HMI (which requires no external configuration program) or by using the VisiSet™
Setup Wizard for easy setup. These procedures are described in chapter 1.
For other applications use VisiSet™ through the reader serial ports.
For Ethernet applications, connections to VisiSet™ can be made directly
through the Ethernet port of the reader (Ethernet models only), or QL500 or
BM2x0 Host Interface module. See the "Configuration Through Ethernet"
page in the VisiSet™ Help On-Line, or the "Matrix Family Setup Procedure
Using Programming Barcodes" document on the Mini-DVD.
8.1 VISISET™ SYSTEM REQUIREMENTS
To install and run VisiSet™ you should have a Laptop or PC that meets or exceeds the
following:
Pentium processor
Windows 98/2000, NT 4.0, XP, Vista or 7
32 MB Ram
5 MB free HD space
one free RS232 serial port with 115 Kbaud
Video Adapter (1024 x 768) or better using more than 256 colors
8.2 INSTALLING VISISET™
To install VisiSet™, proceed as follows:
1. Turn on the Laptop or PC that will be used for configuration (connected to the Matrix
210™ communication ports).
2. After Windows finishes booting, insert the Mini-DVD provided.
3. Launch VisiSet™ installation by clicking Install.
4. Follow the instructions in the installation procedure.
