8.3 STARTUP
After completing the mechanical and electrical connections to Matrix 210™, you can begin
software configuration as follows:
1. Power on the Matrix 210™ reader. Wait for the reader startup. The system bootstrap
requires a few seconds to be completed. The reader automatically enters Run Mode.
2. Run the VisiSet™ program.
3. Press Connect on the VisiSet™ menu bar. The PC will automatically connect to the
Matrix 210™ reader.
Upon connection, Matrix 210™ exits Run Mode and displays the Main Menu on VisiSet™
with all the commands necessary to monitor your reader's performance. You can select
these commands using the mouse or by pressing the key corresponding to the letter
shown on the button. See Figure 108.
Figure 108 - Main Window
