Datalogic Matrix 210 User Manual

TECHNICAL FEATURES
125
11
11 TECHNICAL FEATURES
ELECTRICAL FEATURES
Matrix 210 21x-x0x
Matrix 210 21x-x1x
Matrix 210 21x-x2x
Power
Supply Voltage
10 to 30 Vdc
10 to 30 Vdc
5 Vdc
Consumption
0.35 to 0.13 A, 3.9 W
max.
0.4 to 0.15 A, 4.5 W max
0.5 A, 2.5 W max
0.16 A @ 24 V.
0.18 A @ 24 V
Communication Interfaces
Main
- RS232
- RS485 full-duplex
- RS485 half-duplex
2400 to 115200 bit/s
2400 to 115200 bit/s
2400 to 115200 bit/s
2400 to 115200 bit/s
2400 to 115200 bit/s
2400 to 115200 bit/s
USB 2.0 up to 921600
bit/s
Auxiliary - RS232
2400 to 115200 bit/s
2400 to 115200 bit/s
ID-NET™
Up to 1MBaud
Up to 1MBaud
Ethernet
10/100 Mbit/s
Inputs
Input 1 (External Trigger) and Input 2
Opto-coupled and polarity
insensitive
Opto-coupled and polarity
insensitive
Max. Voltage
30 Vdc
30 Vdc
Max. Input Current
10 mA
10 mA
Outputs
Output 1 and Output 2
Opto-coupled
Opto-coupled
V
Out
(I
Load
= 0 mA) Max.
30 Vdc
30 Vdc
V
Out
(I
Load
= 10 mA) Max.
1.8 Vdc
1.8 Vdc
P
D
= V
Out
I
Load
Max.
170 mW
170 mW
OPTICAL FEATURES
Image Sensor
CMOS sensor with Global Shutter
Image Format
WVGA (752x480)
Frame Rate
up to 60 frames/sec. @ full window size
Pitch
35°
Tilt
0° - 360°
Lighting System
Internal Illuminator
LED Safety
to EN 62471
ENVIRONMENTAL FEATURES
Operating Temperature *
0 to 50 C (32 to 122 °F)
Storage Temperature
-20 to 70 C (-4 to 158 °F)
Max. Humidity
90% non condensing
Vibration Resistance
EN 60068-2-6
14 mm @ 2 to 10 Hz; 1.5 mm @ 13 to 55 Hz;
2 g @ 70 to 200 Hz; 2 hours on each axis
Bump Resistance
EN 60068-2-29
30g; 6 ms;
5000 shocks on each axis
Shock Resistance
EN 60068-2-27
30g; 11 ms;
3 shocks on each axis
Protection Class
EN 60529
IP65
PHYSICAL FEATURES
Matrix 210 21x-1xx models
Matrix 210 21x-0xx models
Dimensions
50 x 25 x 45 mm (1.97 x 0.98 x 1.77 in)
54 x 32 x 45 mm (2.13 x 1.26 x 1.77 in)
Weight
204 g. (7.2 oz.) with cable
190 g. (6.7 oz.) with cable
Material
ZAMA
Aluminium alloy
* high ambient temperature applications should use metal mounting bracket for heat dissipation
